HNR

MAIN FEATURES

4 poles electrical motor (1450 RPM) with thermal protection and water cooling (mod. 1713 LP/2017 LP)
Three ceramic coated pistons (mod. 1509 LP/2017 LP).
Three full ceramic pistons (mod. 1713 LP).
Built-in by-pass valve nickel plating brass linear pump head with high temperature water seals and bushing.
Suction and delivery S. S. valves.
Low voltage and delayed Total Stop (mod. 1713 LP/2017 LP)
Detergent built-in tank for indirect suction (2,8 lt.).
Pressure regulator.
Glicerine pressure gauge.
Hose-reel.

HNR

MAIN FEATURES

4 poles electrical motor (1450 RPM) with thermal protection and water cooling (mod. 1713 LP/2017 LP)
Three ceramic coated pistons (mod. 1509 LP/2017 LP).
Three full ceramic pistons (mod. 1713 LP).
Built-in by-pass valve nickel plating brass linear pump head with high temperature water seals and bushing.
Suction and delivery S. S. valves.
Low voltage and delayed Total Stop (mod. 1713 LP/2017 LP)
Detergent built-in tank for indirect suction (2,8 lt.).
Pressure regulator.
Glicerine pressure gauge.
Hose-reel.

TECHNICAL FEATURES

HNR 1509 LP 1713 LP 2017 LP

Product code

36089-00013

Operating pressure (bar)

150

Max pressure (bar)

160

Delivery rate (l/h)

540

Absorbed power (W)

3000

power supply (V-Hz)

230-50

Pump type / RPM

MP3Ni/1450

Max. inlet temperature (°C)

Product dimensions (cm)

76x40x75

Packaging dimensions (cm)

76x41x75

Weight (Kg)

Product code

36089-00014

Operating pressure (bar)

170

Delivery rate (l/h)

780

Absorbed power (W)

5200

power supply (V-Hz)

400-50

Pump type / RPM

MPW3.5Ni/1450

Max. inlet temperature (°C)

Product dimensions (cm)

76x40x75

Packaging dimensions (cm)

76x41x75

Weight (Kg)

Product code

36089-00015

Operating pressure (bar)

200

Delivery rate (l/h)

1000

Absorbed power (W)

7500

power supply (V-Hz)

400-50

Pump type / RPM

MPW3.5Ni/1450

Max. inlet temperature (°C)

Product dimensions (cm)

76x40x75

Packaging dimensions (cm)

76x41x75

Weight (Kg)

TECHNICAL DOCUMENTS

Technical data sheet

Product instruction manual

INCLUDED ACCESSORIES

Plus

OTHER PRODUCTS IN THE RANGE

INCLUDED ACCESSORIES

GUN AL55 350bar 45 l/min 160°C - swivel inlet 3/8M - cod. 00080-01695

ZNT LANCE FOR HIGH/LOW PRESSURE - cod. 00080-01724

H.P. NOZZLE 15° D. 030 1/8M - cod. 00080-03185

HIGH PRESSURE HOSE 10m 3/8 1/4 - cod. 00080-02258

Plus

Pump with nickel-plated brass head

The nickel-plating tratment improves the resistance to the chemical products used in washing and the hardness of the surface reducing deterioration caused by cavitation
