LITE

MAIN FEATURES

  • Three steel pistons, brass axial pump head with built-in by-pass valve.
  • Easy to transport thanks to a practical top grip and anti-vibration supports.
  • Induction 2-pole motor (2800 rpm).
  • Glicerine pressure gauge.
  • EASY START device.
  • Total Stop system.
  • Rotary switch.
  • Motor thermal protection.

LITE

MAIN FEATURES

  • Three steel pistons, brass axial pump head with built-in by-pass valve.
  • Easy to transport thanks to a practical top grip and anti-vibration supports.
  • Induction 2-pole motor (2800 rpm).
  • Glicerine pressure gauge.
  • EASY START device.
  • Total Stop system.
  • Rotary switch.
  • Motor thermal protection.
Share:


TECHNICAL FEATURES

LITE 1510 XP

Product code

36016-00019

Operating pressure (bar)

135

Max pressure (bar)

150

Delivery rate (l/h)

600

Absorbed power (W)

2900

power supply (V-Hz)

230-50

Pump type / RPM

GXR/2800

Max. inlet temperature (°C)

60

Product dimensions (cm)

26x47x37

Packaging dimensions (cm)

30x50x40

Weight (Kg)

25

TECHNICAL DOCUMENTS



Technical data sheet
Product instruction manual

INCLUDED ACCESSORIES


GUN BIT105 WITH CONNECTIONS G1/4M - M22X1,5F - cod. 00080-02576

Plus

201 - testata ottone.jpg

Brass Head

Brass pump head, robust and performing it is ideal for intense use

203-maniglia trasporto lite.jpg

Transport Handle

Thanks to its practical handle, the high pressure cleaner can be easily transported wherever it is needed


Pressure Gauge

In a glycerine bath to monitor the high pressure cleaner operating pressure at any time

OTHER PRODUCTS IN THE RANGE LITE

Video

Related products

OPTIONAL ACCESSORIES


ROTATING NOZZLE LANCE - cod. 10002-03655
