TEXAS-R

MAIN FEATURES

  • 4 poles electrical motor (1450 RPM) with thermal protection.
  • Three ceramic coated pistons (1 ph), full ceramic  pistons (3 ph), brass linear pump head with built-in by-pass valve.
  • Low voltage and delayed Total Stop.
  • Suction and delivery S. S. valves.
  • Vertical burner with high thermal efficiency steel coil.
  • Temperature regulation gauge with high sensitive stainless steel sensor.
  • Detergent built-in tank (4,2 lt) for indirect suction.
  • Auxiliary motor for burner.
  • Hose reel with brake (optional).

TEXAS-R

MAIN FEATURES

  • 4 poles electrical motor (1450 RPM) with thermal protection.
  • Three ceramic coated pistons (1 ph), full ceramic  pistons (3 ph), brass linear pump head with built-in by-pass valve.
  • Low voltage and delayed Total Stop.
  • Suction and delivery S. S. valves.
  • Vertical burner with high thermal efficiency steel coil.
  • Temperature regulation gauge with high sensitive stainless steel sensor.
  • Detergent built-in tank (4,2 lt) for indirect suction.
  • Auxiliary motor for burner.
  • Hose reel with brake (optional).
Share:


TECHNICAL FEATURES

TEXAS-R 1211 LP 1611 LP

Product code

36080-00002

Operating pressure (bar)

120

Max pressure (bar)

150

Delivery rate (l/h)

660

Absorbed power (W)

3000

power supply (V-Hz)

230-50

Pump type / RPM

MP3/1450

Heat output (kW)

58

Max. inlet temperature (°C)

40

Max. output temperature (°C)

140

Product dimensions (cm)

85x65x97

Packaging dimensions (cm)

69x85x111

Weight (Kg)

112

TECHNICAL DOCUMENTS



Technical data sheet
Product instruction manual

INCLUDED ACCESSORIES


GUN AL55 350bar 45 l/min 160°C - swivel inlet 3/8M - cod. 00080-01695


STAINLESS STEEL LANCE 700mm PL4/1 QUICK CONNECTION M22 - cod. 00080-01715


HIGH PRESSURE NOZZLE 1/8''M 15045 - cod. 00080-03188


HIGH PRESSURE HOSE R1 1/4 8m 3/8F-M22 (MAX 21MPa) - cod. 00080-02254

Plus

201 - testata ottone.jpg

Brass Head

Brass pump head, robust and performing it is ideal for intense use

208-caldaia verticale.jpg

Vertical Burner

With high thermal efficiency steel coil and run on diesel fuel

211_Giri motore.jpg

Motor Low Rotation Speed

The lower rotation speed of the components grants longer pump life

OTHER PRODUCTS IN THE RANGE Texas

HSR

Related products

OPTIONAL ACCESSORIES


KIT HOSE REEL - cod. 10001-10254
