THERMIC 10.1D

High Pressure Cleaner with Combustion Engine and Self Priming Pump

MAIN FEATURES

  • Three ceramic pistons, brass linear pump head with built-in by-pass valve.
  • 1560 RPM gear box between engine and pump.
  • By-pass with thermostatic valve.
  • Automatic RPM regulation.
  • Electrical start with engine functions control.
  • Yanmar L100V Diesel engine (air cooled) with integrated diesel tank.
  • Integrated adjustable detergent suction with external suction probe.
  • Pressure regulator.
  • Glicerine pressure gauge.
  • Suction hose with check valve (optional).
  • Heavy duty steel frame.
  • Battery included.
  • Brass filter.
  • Pneumatic effect d. 260 mm wheels with brake.

THERMIC 10.1D

High Pressure Cleaner with Combustion Engine and Self Priming Pump

MAIN FEATURES

  • Three ceramic pistons, brass linear pump head with built-in by-pass valve.
  • 1560 RPM gear box between engine and pump.
  • By-pass with thermostatic valve.
  • Automatic RPM regulation.
  • Electrical start with engine functions control.
  • Yanmar L100V Diesel engine (air cooled) with integrated diesel tank.
  • Integrated adjustable detergent suction with external suction probe.
  • Pressure regulator.
  • Glicerine pressure gauge.
  • Suction hose with check valve (optional).
  • Heavy duty steel frame.
  • Battery included.
  • Brass filter.
  • Pneumatic effect d. 260 mm wheels with brake.
Share:


TECHNICAL FEATURES

THERMIC 10.1D 1621 2016

Product code

36022-00030

Operating pressure (bar)

160

Delivery rate (l/h)

1260

Pump type / RPM

CL6.0/1560

Max. inlet temperature (°C)

60

Motor type / HP

Yanmar L100V/9.3

Product dimensions (cm)

95x68x83

Packaging dimensions (cm)

95x68x95

Weight (Kg)

124

TECHNICAL DOCUMENTS



Technical data sheet

INCLUDED ACCESSORIES


GUN AL55 350bar 45 l/min 160°C - swivel inlet 3/8M - cod. 00080-01695


700mm M22 LANCE H/L PRESSURE - cod. 10002-04732


H.P. HOSE 10m - cod. 10002-04109

Plus

201 - testata ottone.jpg

Brass Head

Brass pump head, robust and performing it is ideal for intense use

206-robusto telaio in acciaio.jpg

Steel Frame

Sturdy, with a high guarantee of durability, resistant to stress and accidental impacts

204-regolatore di pressione.jpg

Pressure Regulator

It allows to adjust the pressure according to use and needs

OTHER PRODUCTS IN THE RANGE THERMIC

Related products

OPTIONAL ACCESSORIES


SUCTION HOSE SET - cod. 10002-12275
